Brand: Widia / Part #: 2003573

Brand: Widia / Part #: 2003573


Item #: 09903162
Brand: Widia
Model #: 2003573

Product Specifications

Minimum Cutting Diameter (Decimal Inch) 2.0000
Maximum Cutting Diameter (Decimal Inch) 2.0000
Maximum Depth of Cut (Decimal Inch) 0.6350
Arbor Hole Diameter (Decimal Inch) 0.7500
Compatible Insert Size Code XD.T1704..
Maximum Ramping Angle 3
Cutter Style VSM
Cutting Direction Right Hand
Insert Holding Method Screw
Lead Angle 90
Rake Negative (Radial); Positive (Axial)
Rake Angle -6.200
Series VSM17
Maximum Body Diameter (Decimal Inch) 1.9100
Overall Height (Decimal Inch) 1.5750
Keyway Width (mm) 8.19
Hub Diameter (Decimal Inch) 1.7500
Maximum RPM 25600.000
Tool Application Milling; Slotting; Ramping
Tool Performance General Purpose
Primary Workpiece Material Universal
Number of Adjustable Pockets 0
ISO Number VSM17D200Z05S075XD17
Coolant Hole Diameter (Decimal Inch) 0.0980
Complete Insert Compatibility XD_T1704__PE_R___
Toolholder Material Steel
Manufacturers Catalog Number VSM17D200Z05S075XD17
Coolant Through Yes
Number Of Cutter Inserts 5
Number Of Flutes 5
$545.94
