DA Straight Shank Holders

DA Series Collet Extensions

Fits standard double angle (DA) collets
Crafted from heat treated alloy steel
Available with round shank
Supplied with hex collet nut

Prices are pulled from our database in real time. Press Add button to see product price.

Collet Series	Shank D	C	OAL	Max Dia Thru Shank	Nut Dia	Length of Nut	Part Number	Collet Nut Part Number	Wrench Hex Size	Nut Thread
DA 100	1.000	3.00	4.00	9/16	1.06	0.900	S-D10R10-30H-F	CN-DA10S10-F	7/8	-
DA 100	1.000	3.00	4.00	.586	1.43	0.900	S-D10R10-30H-K	CN-DA10S09-K	1-1/4	1"-14
DA 100	1.000	5.62	7.30	9/16	1.06	1.540	S-D10R10-56H-F	CN-DA10E10-F	7/8	-
DA 100	1.000	5.62	7.30	.590	1.43	0.900	S-D10R10-56H-K	CN-DA10S09-K	1-1/4	1"-14
DA 180	1.000	5.00	6.20	3/4	1.56	0.870	S-D18R10-50H-F	CN-DA18S18-F	1-3/8	-
DA 180	1.000	5.00	6.20	.668	1.72	0.900	S-D18R10-50H-K	CN-DA18S09-K	1-1/2	1-1/4"-12
DA 180	1.250	5.00	6.20	3/4	1.56	0.870	S-D18R12-50H-F	CN-DA18S18-F	1-3/8	-
DA 180	1.250	5.00	6.20	.718	1.72	0.900	S-D18R12-50H-K	CN-DA18S09-K	1-1/2	1-1/4"-12
DA 180	1.500	5.00	6.20	3/4	1.56	0.870	S-D18R15-50H-F	CN-DA18S18-F	1-3/8	-
DA 180	1.500	5.00	6.20	.866	1.72	0.900	S-D18R15-50H-K	CN-DA18S09-K	1-1/2	1-1/4"-12
DA 180	1.750	5.00	6.20	3/4	1.56	0.870	S-D18R17-50H-F	CN-DA18S18-F	1-3/8	-
DA 180	1.750	5.00	6.20	.866	1.72	0.900	S-D18R17-50H-K	CN-DA18S09-K	1-1/2	1-1/4"-12
DA 200	0.625	3.00	3.75	3/8	0.75	0.710	S-D20R06-30H-F	CN-DA20S06-F	11/16	-
DA 200	0.625	3.00	3.75	.453	1.14	0.758	S-D20R06-30H-K	CN-DA20S07-K	1"	3/4"-16
DA 200	0.750	3.00	3.80	3/8	0.81	0.710	S-D20R07-30H-F	CN-DA20S07-F	3/4	-
DA 200	0.750	3.00	3.80	.478	1.14	0.758	S-D20R07-30H-K	CN-DA20S07-K	1"	3/4"-16
DA 200	0.750	5.62	7.10	3/8	0.81	1.340	S-D20R07-56H-F	CN-DA20E07-F	11/16	-
DA 200	0.750	5.62	7.10	.478	1.14	0.758	S-D20R07-56H-K	CN-DA20S07-K	1"	3/4"-16
DA 300	0.500	2.75	3.60	1/4	0.56	0.700	S-D30R05-27H-F	CN-DA30S05-F	1/2	-
DA 300	0.500	2.75	3.60	.343	0.76	0.729	S-D30R05-27H-K	CN-DA30S07-K	11/16	9/16"-18
DA 300	0.500	5.62	6.80	1/4	0.56	1.000	S-D30R05-56H-F	CN-DA30E05-F	1/2	-
DA 300	0.500	5.62	6.80	.343	0.76	0.729	S-D30R05-56H-K	CN-DA30S07-K	11/16	9/16"-18
DA 300	0.625	3.20	3.75	1/4	0.56	0.700	S-D30R06-32H-F	CN-DA30S05-F	1/2	-
DA 300	0.625	3.20	3.75	.343	0.76	0.729	S-D30R06-32H-K	CN-DA30S07-K	11/16	9/16"-18
