Radial Drill Press - #TPR1230 - 48-1/2'' Swing; 2HP, 3PH, 220V Motor

Item #: RL84TPR1230
Manufacturer: PRM
Mfg #: :

Technical Specifications:
•Base Dimensions (in.): - •Brand Name: PRM •Column Diameter (in.): 11-3/16 •Distance From Base to Spindle (min/max in.): 19-3/8 - 54 •Distance From Column to Spindle (min/max in.): 48-1/2 •Drilling Capacity Cast Iron (in.): 2-3/16 •Drilling Capacity Steel (in.): 1-5/8 •Feed Rates: .002, .004, .006 •Model Number: TPR1230 •Motor: 2HP, 220V, 3PH •Quill Travel (in.): 9-7/8 •Range of Speeds (RPM): 44 - 1500 •Spindle Taper: 4MT •Swing (in.): 48-1/2 •Table Dimensions (in.): 27-5/8 x 19-5/8 x 15-3/4 •Tapping Capacity Cast Iron (in.): 1-1/2 •Tapping Capacity Steel (in.): 1 •Travel of Arm (Vertical in.): 34-5/8 •Travel of Head (in.): 35 •Weight: 5620 lbs

Description:
•High speed nickel chrome steel gears mounted on splined steel shafts turning in anti-friction bearings •Columns are designed for maximum rigidity and minimum deflection while machining •Arm is ribbed to avoid stress from twisting •Carbon steel spindle is spline driven and loaded with large diameter taper roller bearings for maximum accuracy •Coolant tank is incorporated into the base casting •1 Year Warranty Parts •F.O.B. WARREN, MI •Standard Equipment:•4MT spindle taper, heavy duty non-tilting large box table, coolant system built into base, work light, 3-phase heavy duty motor and electric controls with overload protection

Shipping Info:
•Commercial Truck - Call for Shipping Charges •Actual Weight - 4620.0000
