Brand: Widia / Part #: 2831727

Brand: Widia / Part #: 2831727


Item #: 02772135
Brand: Widia
Model #: 2831727

Product Specifications

Minimum Bore Diameter (Decimal Inch) 0.3600
Maximum Bore Depth (Decimal Inch) 1.7500
Toolholder Style CCPI
Tool Material Carbide
Shank Diameter (Decimal Inch) 0.2500
Hand of Holder Right Hand
Shank Diameter (Inch) 1/4
Overall Length (Decimal Inch) 6.0000
Overall Length (Inch) 6
Compatible Insert Size Code GP..12105
Insert Holding Method Screw
Compatible Insert Shape Diamond
Insert Included No
Rake Positive
Cutting Direction Right Hand
Rake Angle 0.000
Lead Angle 0.000
Series CCPI
Insert Inscribed Circle (Inch) 5/32
Compatible Insert Thickness (Decimal Inch) 0.0625
Compatible Insert Thickness (mm) 1.59
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (Decimal Inch) 0.3450
Center to Cutting Edge (Decimal Inch) 0.2200
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Insert Thickness (Decimal Inch) 0.0625
Insert Thickness (Inch) 1/16
Coolant Hole Diameter (Decimal Inch) 0.0470
Number of Inserts Included in Order 0
Manufacturers Catalog Number CCPI25060R
Radial Rake 0
Coolant Through Yes
$304.43
