Brand: Widia / Part #: 4169578

Brand: Widia / Part #: 4169578


Item #: 93307460
Brand: Widia
Model #: 4169578

Product Specifications

Insert Style WMTC
Insert Size Code 094R
Insert Material Carbide
Manufacturer Grade WU25PT
Cutting Width (Decimal Inch) 0.0940
Cutting Width (Inch) 3/32
Insert Holding Method Clamp
Lead Angle Direction Right Hand
Insert Hand Right Hand
Lead Angle 5.000
Relief Angle 5.000
Corner Radius (mm) 0.13
Corner Radius (Decimal Inch) 0.0050
Chipbreaker CM
Multi-use Tool No
Cutting Tool Application Cut-Off
Series WMTC
Coating Process PVD
Overall Length (Decimal Inch) 0.8790
Primary Workpiece Material Super-alloys & Titanium
Primary Workpiece Material Code S
Secondary Workpiece Material Non-Ferrous Metal; Stainless Steel; Cast Iron; Steel
Secondary Workpiece Material Code P; K; M; N
Ansi Code WMTC094R05CM13
Iso Code WMTC094R05CM13
Cutting Height (Decimal Inch) 0.1650
Manufacturers Catalog Number WMTC094R05CM13
Insert Seat Size 2B
Cutting Direction Right Hand
Maximum Depth of Cut (Decimal Inch) 0.8790
Coating Classification PVD
Insert Width (Decimal Inch) 0.0740
Overall Width (Decimal Inch - 4 Decimals) 0.0940
Coating/Finish AlTiN
Single Or Double End Double
$29.01
