Brand: Widia / Part #: 2892518

Brand: Widia / Part #: 2892518


Item #: 99726952
Brand: Widia
Model #: 2892518

Product Specifications

Thread Type Internal
Hand of Holder Right Hand
Shank Width/Diameter (Decimal Inch) 0.3750
Compatible Insert Size Code 2
Shank Width/Diameter (Inch) 3/8
Toolholder Style LSER
Insert Compatibility LT11NR
Coolant Entry Style Code 1-Axial Concentric Entry
Insert Holding Method Screw; Clamp
Shank Height (Decimal Inch) 0.0000
Shank Length (Inch) 8
Shank Length (Decimal Inch) 6.0000
Overall Length (Inch) 6
Overall Length (Decimal Inch) 6.0000
Minimum Bore Diameter (Decimal Inch) 0.5000
Series E-LSE
Multi-use Tool No
Cutting Tool Application Threading
Maximum Depth of Cut (Decimal Inch) 0.0300
Adjustable Overhang Yes
Back of Bar to Cutting Edge (Decimal Inch) 0.4675
Center to Cutting Edge (Decimal Inch) 0.2800
Insert Inscribed Circle (Decimal Inch) 0.2500
Insert Inscribed Circle (Inch) 1/4
Insert Inscribed Circle (mm) 6.35
Primary Workpiece Material Code P; S; H; K; M; N; O
Coolant Hole Diameter (Decimal Inch) 0.1250
Toolholder Material Carbide
Insert Thickness (Decimal Inch) 0.1248
Style LSER
Coolant Through Yes
$299.91
