Brand: Widia / Part #: 2832172

Brand: Widia / Part #: 2832172


Item #: 19615178
Brand: Widia
Model #: 2832172

Product Specifications

Minimum Bore Diameter (Decimal Inch) 0.2180
Maximum Bore Depth (Decimal Inch) 1.3125
Toolholder Style CCBI
Tool Material Carbide
Shank Diameter (Decimal Inch) 0.1875
Hand of Holder Left Hand
Shank Diameter (Inch) 3/16
Overall Length (Decimal Inch) 6.0000
Overall Length (Inch) 6
Compatible Insert Size Code CD..120605
Insert Holding Method Screw
Compatible Insert Shape Diamond
Insert Included No
Rake Positive
Cutting Direction Left Hand
Rake Angle 0.000
Lead Angle -5.000
Series CCBI
Insert Inscribed Circle (Inch) 5/32
Compatible Insert Thickness (Decimal Inch) 0.0400
Compatible Insert Thickness (mm) 1.02
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (Decimal Inch) 0.2048
Center to Cutting Edge (Decimal Inch) 0.1110
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Insert Thickness (Decimal Inch) 0.0400
Coolant Hole Diameter (Decimal Inch) 0.0400
Number of Inserts Included in Order 0
Manufacturers Catalog Number CCBI18765L
Radial Rake 5
Coolant Through Yes
$332.37
