Ballnose End Mill; 7/32″ Dia. × 1/2″ LOC × 1/4″ Shank Dia. × 2-1/2″ OAL, 4 FL, Carbide, Uncoated
Item #: TA15TC14614
Brand: Titan USA
Model #: TC14614
| Product Specifications | |
|---|---|
| Cutting Diameter (DC) | 7/32″ |
| Flute Helix Angle (FHA) | 30 Degrees |
| Connection Diameter Machine Side (DCONMS) | 1/4″ |
| Usable Length (LU) | 1/2″ |
| Depth of Cut Maximum (APMX) | 1/2″ |
| Corner Radius (RE) | 7/64″ |
| Overall Length (OAL) | 2-1/2″ |
| End Shape | Ball |
| Cutting Edge Material | Carbide |
| Decimal Equivalent | 0.2188″ |
| Coating | Uncoated |
| Measurement Type | Inch |
| Flute Count (NOF) | 4 |
| Center Cutting | Yes |
