Brand: Sandvik Coromant / Part #: 8412616

Brand: Sandvik Coromant / Part #: 8412616


Item #: 67707513
Brand: Sandvik Coromant
Model #: 8412616

Product Specifications

Mill Diameter (mm) 20.00
Corner Radius (mm) 0.50
Coating/Finish Uncoated
End Mill Material Solid Carbide
Number Of Flutes 3
Single Or Double End Single
Overall Length (mm) 111.0000
Length of Cut (mm) 30.0000
Cutting Direction Right Hand
Coolant Through No
Mill Diameter (Decimal Inch) 0.0310
Flute Direction Right Hand
Helix Angle 35
Chipbreaker No
End Type Corner Radius
Length Type Short
Extended Reach Yes
Shank Type Weldon
Centercutting Yes
Variable Helix Yes
Material Removal Type Roughing & Finishing
Shank Diameter (mm) 20.0000
Neck Diameter (mm) 19.200
Neck Diameter (Decimal Inch) 0.7559
Minimum Helix Angle 25
Maximum Helix Angle 35
Primary Workpiece Material Non-Ferrous Metal
Primary Workpiece Material Code N
Material Grade H10F
Series CoroMill? Dura
Material Application Non-Ferrous Metal
Coating Classification Uncoated
Helix Style Variable
Manufacturers Catalog Number 1K223-2000-050-NH H10F
$358.48
