1/4″-28 UNF H7 3 Flute HSS-E TiAlN Modified Bottoming Spiral Flute Tap
Item #: FK107849615
Brand: Walter-Prototyp
Model #: 7849615
| Product Specifications | |
|---|---|
| Thread Diameter Size (TDZ) | 1/4″ |
| Thread Tolerance Class (TCTR) | H7 |
| Threads per Inch (TPI) | 28 |
| Chamfer | Modified Bottom |
| Thread Standard | UNF |
| Coating | TiAlN |
| Overall Length (OAL) | 82.73 mm |
| Flute Length | 26 mm |
| Usable Length (LU) | 30 mm |
| Cutting Direction (HAND) | Right Hand |
| Connection Diameter Machine Side (DCONMS) | 0.255″ |
| Coolant Supply Property (CSP) | External |
| Flute Count (NOF) | 3 |
| Measurement Type | Inch |
| Flute Helix Angle (FHA) | 40 Degrees |
| Grade | WY80RG |
| Applicable Material | Steel | Stainless Steel | Cast Iron | Aluminum / Non-Ferrous Materials |
| ToolTypeName | Spiral Flute Taps |
| Cutting Edge Material | HSS-E |
