Brand: Widia / Part #: 2031025

Brand: Widia / Part #: 2031025


Item #: 02779031
Brand: Widia
Model #: 2031025

Product Specifications

Minimum Bore Diameter (mm) 20.000
Maximum Bore Depth (mm) 112.00
Toolholder Style SDQCR
Tool Material Carbide
Shank Diameter (mm) 16.0000
Hand of Holder Right Hand
Overall Length (mm) 200.0000
Compatible Insert Size Code DC..070204
Insert Holding Method Screw
Compatible Insert Shape Diamond
Insert Included No
Rake Positive
Cutting Direction Right Hand
Rake Angle -5.000
Lead Angle 108.000
Series E-SDQC
Insert Inscribed Circle (Inch) 1/4
Compatible Insert Thickness (Decimal Inch) 0.0938
Compatible Insert Thickness (mm) 2.38
Multi-use Tool Yes
Cutting Tool Application Boring
Back of Bar to Cutting Edge (mm) 19.00
Center to Cutting Edge (mm) 11.00
Primary Workpiece Material Universal
Multi-Use Application Boring
Number of Inserts Used on Toolholder 1
Insert Thickness (Decimal Inch) 0.0938
Insert Thickness (Inch) 3/32
Coolant Hole Diameter (mm) 5.50
Number of Inserts Included in Order 0
Manufacturers Catalog Number E16RSDQCR07
Radial Rake 0
Coolant Through Yes
