Iscar - 63mm Min Bore Diam, 450mm OAL, 50mm Shank Diam, S-PCLN Indexable Boring Bar - 70mm Max Bore Depth, CN.. 1906.. Insert, Clamp Holding Method
Item #: 91110734
Brand: Iscar
Model #: 3690478
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Toolholder Style | S-PCLN |
| Series | Isoturn |
| Minimum Bore Diameter (mm) | 63.00 |
| Hand of Holder | Right Hand |
| Maximum Bore Depth (mm) | 70.00 |
| Overall Length (mm) | 450.00 |
| Shank Diameter (mm) | 50.00 |
| Insert Compatibility | CN.. 1906.. |
| Through Coolant | No |
| Multi-Use Tool | No |
| Insert Holding Method | Clamp |
| Rake | Negative |
| Center to Cutting Edge (mm) | 35.00 |
| Insert Inscribed Circle (mm) | 19.05 |
| Rake Angle | -8.5 |
| Complete Insert Compatibility | CNGG 190612-PP; CNGG 190612-TF; CNMA 190612; CNMA 190616; CNMG 190608-GN; CNMG 190608-NR; CNMG 190612-GN; CNMG 190612-NR; CNMG 190612-PP; CNMG 190612-TF; CNMG 190616-NR; CNMG 190624-NR; CNMM 190612-NM; CNMM 190616-NM; CNMM 190624-H3P; CNMM 190624-H4P |
| Toolholder Material | Steel |
