Kennametal - 0505A4G GUP Grade KCP25, 5.05mm Cutting Width Carbide Grooving Insert - 4.2mm Max Depth of Cut, Neutral, 0.4mm Corner Radius, TiN Finish
Item #: 89538896
Brand: Kennametal
Model #: 3791308
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | A4G |
| Insert Size | 0505 |
| Material | Carbide |
| Cutting Width (mm) | 5.05 |
| Cutting Width (Decimal Inch) | 0.1988 |
| Maximum Depth of Cut (mm) | 4.20 |
| Maximum Depth of Cut (Decimal Inch) | 0.1654 |
| Material Grade | C2/C3/C6/C7 |
| Manufacturer's Grade | KCP25 |
| Coating | TiN |
| Insert Hand | Neutral |
| Insert Seat Size | 5 |
| Chipbreaker | GUP |
| Multi-Use Tool | No |
| Corner Radius (mm) | 0.40 |
| Corner Radius (Decimal Inch) | 0.0157 |
| Coating Process | CVD |
| Overall Length (mm) | 25.15 |
| Overall Length (Decimal Inch) | 0.9902 |
| Series | A4 |
| Rake | Positive |
