Iscar - 1.969" Body Diam, Manual Single Cutter Boring Head - 0.236" to 0.866" Bore Diam, 0.63" Bar Hole Diam
Item #: 86563467
Brand: Iscar
Model #: 4550956
Exact Tooling IR#: 04
Features and Benefits
Boring heads with a single cutter (single edge) are used for general purpose finishing and roughing operations. They may also be used where machine power is limited.
Integral shank boring heads have the shank built into the head.
| Product Specifications | |
|---|---|
| Type | Single Cutter Boring Head |
| Actuation Type | Manual |
| Body Diameter (Decimal Inch) | 1.9690 |
| Mount Type | Integral Shank |
| Shank Type | Modular Connection |
| Modular Connection Size | MB50 |
| Series | Itsbore |
| Boring Bar Hole Diameter (Decimal Inch) | 0.6300 |
| Minimum Bore Diameter (Decimal Inch) | 0.2360 |
| Maximum Bore Diameter (Decimal Inch) | 0.8660 |
| Projection (Decimal Inch) | 2.7000 |
| Diameter Direct Reading (Decimal Inch) | 0.000080 |
