Iscar - GEPI 1.78-0.15 IC08 Carbide Grooving Insert
Item #: 85561645
Brand: Iscar
Model #: 6403387
Product Specifications
| Insert Style | GEPI |
| Insert Size | 1.78-0.15 |
| Material | Carbide |
| Cutting Width (mm) | 1.78 |
| Cutting Width (Decimal Inch) | 0.0700 |
| Maximum Depth of Cut (mm) | 2.50 |
| Maximum Depth of Cut (Decimal Inch) | 0.0980 |
| Material Grade | Fine-grained |
| Manufacturer's Grade | IC08 |
| Coating | Uncoated |
| Relief Angle | 8 |
| Multi-Use Application | Grooving; Parting; Turning |
| Maximum Corner Radius (Decimal Inch) | 0.0060 |
| Corner Radius (mm) | 0.15 |
| Corner Radius (Decimal Inch) | 0.0060 |
| Series | Cut Grip |
| ISO Number | GEPI 1.78-0.15 IC08 |
| Manufacturers Catalog Number | 6403387 |
| Overall Width (mm) | 1.80 |
| Overall Width (Decimal Inch) | 0.0710 |
| Series Number | Cut Grip |
| Corner Radius (Inch) | 0.0060 |
