Enco - 9-3/8 x 6-1/4" Max Capacity, Manual Geared Head Horizontal Bandsaw - 138 & 276 SFPM Blade Speed, 220 Volts, 45 & 60°, 1.5 hp, 3 Phase
Item #: 83717744
Brand: Enco
Exact Tooling IR#: 04
Features and Benefits
Manual bandsaws are controlled by an operator. They manually load the material into the saw, measure lengths to cut and adjust stops.
Geared head drive systems are similar to step pulleys, but are driven by a geared transmission. They offer rapid speed changes by turning a hand dial and feature 3 to 4 fixed speeds
Three-phase refers to three individual lines (coils) that connect to and run voltage through the motor. Each line alternates in a sequence as it reaches its voltage peak. They provide a more stable flow of voltage and more horsepower to the equipment.
| Product Specifications | |
|---|---|
| Machine Style | Manual |
| Drive Type | Geared Head |
| Angle of Rotation | 45; 60 |
| Maximum Capacity (Rectangular) (Inch) | 9-3/8 x 6-1/4 |
| Maximum Capacity (Rounds) (Inch) | 8-3/4 |
| Phase | 3 |
| Voltage | 220 |
| Coolant System | Yes |
| Angular Cuts at 45 Degrees (mm) | 140 (Square); 155 x 115 (Rectangular); 160 (Round) |
| Angular Cuts at 45 Degrees (Inch) | 5-1/2 (Square); 6-1/4 (Round); 6-1/8 x 4-1/2 (Rectangular) |
| Blade Width (mm) | 27.00 |
| Blade Width (Decimal Inch) | 1.0000 |
| Angular Cuts at 60 Degrees (mm) | 90 (Round); 90 (Square); 90x 100 (Rectangular) |
| Angular Cuts at 60 Degrees (Inch) | 3-1/2 (Round); 3-1/2 (Square); 3-1/2 x 3-7/8 (Rectangular) |
| Blade Speeds (SFPM) | 138; 276 |
| Blade Length (Inch) | 96-3/8 |
| Blade Length (mm) | 2460.00 |
| Blade Thickness (mm) | 0.89 |
| Blade Thickness (Decimal Inch) | 0.0350 |
| Blade Speeds (SFPM) | 138; 276 |
| Horsepower (HP) | 1.50 |
| Base Width (mm) | 508.00 |
| Base Width (Inch) | 20 |
| Base Depth (mm) | 1422.40 |
| Base Depth (Inch) | 56 |
