Jet - 7 x 7" Max Capacity, Manual Step Pulley Horizontal Bandsaw - 137 to 275 SFPM Blade Speed, 230 Volts, 45°, 3 Phase
Item #: 81947467
Brand: Jet
Model #: 414464
Exact Tooling IR#: 04
Features and Benefits
Manual bandsaws are controlled by an operator. They manually load the material into the saw, measure lengths to cut and adjust stops.
Step pulleys are driven by a belt system that is manually changed to achieve a specific speed. These pulleys commonly feature 3 to 4 fixed speeds.
Three-phase refers to three individual lines (coils) that connect to and run voltage through the motor. Each line alternates in a sequence as it reaches its voltage peak. They provide a more stable flow of voltage and more horsepower to the equipment.
| Product Specifications | |
|---|---|
| Machine Style | Manual |
| Drive Type | Step Pulley |
| Angle of Rotation | 45 |
| Maximum Capacity (Rectangular) (Inch) | 7 x 7 |
| Maximum Capacity (Rounds) (Inch) | 7 |
| Phase | 3 |
| Voltage | 230 |
| Blade Width (Decimal Inch) | 0.7500 |
| Blade Speeds (SFPM) | 137 - 275 |
| Blade Length (Inch) | 82 |
| Blade Thickness (Decimal Inch) | 0.0350 |
