Milling Insert: APKT 1003PDSR-31 CTCK215, CTCK215, Solid Carbide N/A Finish,
Item #: 79804399
Brand: Ceratizit
Model #: 51041520
Product Specifications
| Insert Style | APKT |
| Insert Size Code | 1003 |
| Insert Material | Solid Carbide |
| Manufacturer Grade | CTCK215 |
| Inscribed Circle (Decimal Inch) | 0.2618 |
| Corner Radius (Decimal Inch) | 0.0197 |
| Insert Hand | Right Hand |
| Relief Angle | 11.00 |
| Series | APKT |
| Coating Process | CVD |
| Hole Diameter (Decimal Inch) | 0.1102 |
| Maximum Depth of Cut (Decimal Inch) | 0.2943 |
| Number Of Cutting Edges | 2 |
| Cutting Edge Effective Length (Decimal Inch) | 0.4252 |
| Insert Shape | Parallelogram |
| Rake | Positive |
| Primary Workpiece Material | Cast Iron |
| Primary Workpiece Material Code | K |
| Iso Code | APKT 1003PDSR-31 CTCK215 |
| Chip Breaker | 31 |
| Coating/Finish | Coated |
| Included Angle Degree | 85 |
| Thickness (Decimal Inch - 4 Decimals) | 0.1378 |
