Brand: Widia / Part #: 2016562
Item #: 99766081
Brand: Widia
Model #: 2016562
Product Specifications
| Connection Type | Arbor |
| Cutting Width (mm) | 10.00 |
| Maximum Depth of Cut (mm) | 63.00 |
| Hole Diameter (Mm) ( - 0 Decimals) | 50.0000 |
| Cutter Diameter (mm) | 200.00 |
| Cutting Direction | Neutral |
| Insert Holding Method | Screw |
| Number Of Cutter Inserts | 18 |
| Compatible Insert Style | SNHX |
| Compatible Insert Size Code | 12L5 |
| Staggered Tooth | Yes |
| Tooth Type | Staggered Tooth |
| Rake | Negative |
| Tool Material | Steel |
| Series | M95 |
| Toolholder Style | M95 |
| Hub Diameter (mm) | 72.010 |
| Tool Application | Slotting |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Minimum Cutting Width (Decimal Inch) | 0.3940 |
| Maximum Cutting Width (mm) | 10.01 |
| Minimum Cutting Diameter (mm) | 200.00 |
| Lead Angle | 90 |
| Maximum Body Diameter (mm) | 200.00 |
| Cutter Body Width (mm) | 10.01 |
| Weldon Flat | No |
| Insert Inscribed Circle (Decimal Inch) | 0.5000 |
| Overall Length (mm) | 12.0000 |
| Insert Inscribed Circle (Inch) | 1/2 |
| Number Of Teeth | 9 |
| Coolant Through | No |
| Complete Insert Compatibility | SNHX |
| Coating/Finish | Coated |
| Overall Height (Mm - 5 Decimals) | 12.00000 |
