Tungaloy - XPMT07H308 DW Grade AH725 Carbide Indexable Drill Insert - TiAlN Finish, Diamond
Item #: 77811396
Brand: Tungaloy
Model #: 6861403
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Titanium aluminum nitride (TiAlN) has a higher hardness than TiN and TiCN. It is extremely heat-resistant and used for high-speed applications on stainless steels, nickel and titanium alloys.
| Product Specifications | |
|---|---|
| Insert Style | XPMT |
| Insert Size | 07H308 |
| Material | Carbide |
| Manufacturer's Grade | AH725 |
| Thickness (mm) | 3.60 |
| Thickness (Decimal Inch) | 0.1420 |
| Corner Radius (mm) | 0.80 |
| Corner Radius (Decimal Inch) | 0.0310 |
| Shape | Diamond |
| Width (Decimal Inch) | 0.3230 |
| Width (mm) | 8.20 |
| Hole Diameter (mm) | 2.80 |
| Hole Diameter (Decimal Inch) | 0.1100 |
| Relief Angle | 11 |
| Coating | TiAlN |
| Coating Process | PVD |
| Cutting Direction | Right Hand |
| Chipbreaker | DW |
