SNMG433RP KCK20 Carbide Turning Insert TiCN/Al2O3 Finish, 1/2″ Inscribed Circle, 3/64″ Corner Radius, 90° Square, Series KENLOC
Item #: 76367374
Brand: Kennametal
Model #: 3753892
Product Specifications
| Insert Style | SNMG |
| Insert Shape Code | S |
| Insert Size Code | 433 |
| Insert Shape | Square |
| Clearance Code | N |
| Tolerance Code | M |
| Insert Material | Solid Carbide |
| Manufacturer Grade | KCK20 |
| Hole Diameter (Mm) ( - 0 Decimals) | 5.16 |
| Hole Diameter (Decimal Inch) | 0.2031 |
| Maximum Depth of Cut (mm) | 1.25 |
| Maximum Depth of Cut (Decimal Inch) | 0.0492 |
| Inscribed Circle (Inch) | 1/2 |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Insert Holding Method | Pin; Clamp |
| Insert Thickness (Inch) | 3/16 |
| Insert Thickness (Decimal Inch) | 0.1875 |
| Corner Radius (Inch) | 3/64 |
| Corner Radius (Decimal Inch) | 0.0469 |
| Included Angle | 90.0 |
| Relief Angle | 0 |
| Series | KENLOC |
| Coating Process | CVD |
| Rake | Positive |
| Primary Workpiece Material | K |
| Iso Code | SNMG433 |
| Material Grade | C3; C2 |
| Chip Breaker | G |
| Rake Angle | 5 |
| Style | SNMG433 |
| Coating/Finish | TiCN; Al2O3 |
