Brand: Widia / Part #: 5094259
Item #: 97247399
Brand: Widia
Model #: 5094259
Product Specifications
| Cutting Direction | Right Hand |
| Hand of Holder | Right Hand |
| Compatible Insert Size Code | TP..2151 |
| Toolholder Style | STGPR |
| Rake | Neutral |
| Rake Angle | 0 |
| Multi-use Tool | Yes |
| Lead Angle | 90.000 |
| Insert Holding Method | Screw |
| Shank Width (Decimal Inch) | 0.5000 |
| Shank Width (Inch) | 1/2 |
| Shank Height (Decimal Inch) | 0.5000 |
| Shank Height (Inch) | 1/2 |
| Series | STGP |
| Overall Length (Decimal Inch) | 3.5000 |
| Overall Length (Inch) | 3-1/2 |
| Cutting Tool Application | Turning |
| Head Length (Decimal Inch) | 0.5600 |
| Back of Bar to Cutting Edge (Inch) | 5/8 |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.6250 |
| Primary Workpiece Material | Universal |
| Center to Cutting Edge (Decimal Inch) | 0.3750 |
| Insert Inscribed Circle (Decimal Inch) | 0.2500 |
| Insert Inscribed Circle (Inch) | 1/4 |
| Insert Width (Decimal Inch) | 0.4331 |
| Toolholder Material | Steel |
| ISO Number | STGPR082V |
| Complete Insert Compatibility | TP..21.5. |
| Manufacturers Catalog Number | STGPR082V |
| Coolant Through | No |
| Insert Thickness (Decimal Inch) | 0.0940 |
