Value Collection - Size 46 Countersunk Head Aluminum Open End Blind Rivet - Aluminum Mandrel, 0.251" to 3/8" Grip, 0.22" Head Diam, 0.129" to 0.133" Hole Diam, 0.525" Length Under Head, 1/8" Body Diam - Industrial Tool & Supply

Value Collection - Size 46 Countersunk Head Aluminum Open End Blind Rivet - Aluminum Mandrel, 0.251" to 3/8" Grip, 0.22" Head Diam, 0.129" to 0.133" Hole Diam, 0.525" Length Under Head, 1/8" Body Diam


Item #: 70976303
Brand: Value Collection
Exact Tooling IR#: 04

Features and Benefits

Open end rivets are used when disassembly is difficult or not required.
Countersunk head rivets lie flush against the workpiece material and have large bearing surfaces.
Aluminum has a high strength-to-weight ratio and is wear resistant, nonmagnetic and conductive. It is easier to form and machine than steel and is naturally noncorrosive.
Aluminum has a high strength-to-weight ratio and is wear resistant, nonmagnetic and conductive. It is easier to form and machine than steel and is naturally noncorrosive.
Product Specifications
Type Open End
Head Type Countersunk
Size Code 46
Rivet Material Aluminum
Mandrel Material Aluminum
Minimum Grip (Decimal Inch) 0.2510
Maximum Grip (Decimal Inch) 0.3750
Head Diameter (Decimal Inch) 0.2200
Minimum Hole Diameter (Decimal Inch) 0.1290
Maximum Hole Diameter (Decimal Inch) 0.1330
Drill Size (Wire) #30
Length Under Head (Decimal Inch) 0.5250
Body Diameter (Decimal Inch) 0.1250
Body Diameter (Inch) 1/8
Shear Strength (Lb.) 155
Tensile Strength (Lb.) 240
Rivet Finish/Coating Bright
Fastener Standard IFI 114 Grade 11
Head Height (Decimal Inch) 0.0310
$25.63
