Value Collection - Size 88 Dome Head Aluminum Structural with Locking Stem Blind Rivet - Aluminum Mandrel, 0.08" to 5/8" Grip, 0.53" Head Diam, 0.261" to 0.272" Hole Diam, 0.81" Length Under Head, 1/4" Body Diam
Item #: 70948245
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
Structural rivets with a locking stem have a locking collar on the stem that creates a watertight, vibration-resistant bond.
Dome head types have domed, cylindrical heads with low profiles. They are commonly used for their large bearing surface and versatility.
Aluminum has a high strength-to-weight ratio and is wear resistant, nonmagnetic and conductive. It is easier to form and machine than steel and is naturally noncorrosive.
Aluminum has a high strength-to-weight ratio and is wear resistant, nonmagnetic and conductive. It is easier to form and machine than steel and is naturally noncorrosive.
| Product Specifications | |
|---|---|
| Type | Structural w/ Locking Stem |
| Head Type | Dome |
| Size Code | 88 |
| Rivet Material | Aluminum |
| Mandrel Material | Aluminum |
| Minimum Grip (Decimal Inch) | 0.0800 |
| Maximum Grip (Decimal Inch) | 0.6250 |
| Head Diameter (Decimal Inch) | 0.5300 |
| Minimum Hole Diameter (Decimal Inch) | 0.2610 |
| Maximum Hole Diameter (Decimal Inch) | 0.2720 |
| Drill Size (Wire) | G |
| Length Under Head (Decimal Inch) | 0.8100 |
| Body Diameter (Decimal Inch) | 0.2500 |
| Body Diameter (Inch) | 1/4 |
| Shear Strength (Lb.) | 1300 |
| Tensile Strength (Lb.) | 950 |
| Rivet Finish/Coating | Bright |
| Head Height (Decimal Inch) | 0.1200 |
