Sumitomo - WDXT063006 L Grade ACK300 Carbide Indexable Drill Insert - TiAlN/AlCrN Finish, Parallelogram, 6mm Inscribed Circle
Item #: 69240133
Brand: Sumitomo
Model #: 1AHD017
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | WDXT |
| Insert Size | 063006 |
| Material | Carbide |
| Manufacturer's Grade | ACK300 |
| Inscribed Circle (mm) | 6.00 |
| Inscribed Circle (Decimal Inch) | 0.2362 |
| Thickness (Decimal Inch) | 0.1181 |
| Corner Radius (Decimal Inch) | 0.0236 |
| Shape | Parallelogram |
| Width (Decimal Inch) | 0.2362 |
| Coating | TiAlN/AlCrN |
| Coating Process | PVD |
| Cutting Direction | Right Hand |
| Chipbreaker | L |
