Kennametal - Series HCP-IQ, 25.8mm Diam Grade IC908 Replaceable Drill Tip - Carbide, TiAlN/TiN Finish, 25 Seat Size
Item #: 68687110
Brand: Kennametal
Model #: 5568065
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
TiAlN/TiN is a multilayer coating that combines the high hardness of TiN and the heat resistance of TiAlN. It is commonly used on softer materials in general purpose applications.
| Product Specifications | |
|---|---|
| Diameter (mm) | 25.80 |
| Diameter (Decimal Inch) | 1.0160 |
| Material | Carbide |
| Material Grade | Submicron |
| Manufacturer's Grade | IC908 |
| Series | HCP-IQ |
| Coating | TiAlN/TiN |
| Insert Seat Size | 25 |
| Through Coolant | No |
| Coating Process | PVD |
| Height (mm) | 14.50 |
| Height (Decimal Inch) | 0.5710 |
| Cutting Diameter (Decimal Inch) | 1.2500 |
| Head Length (Decimal Inch) | 1.7500 |
| ISO Number | M4D125L1503M16L175 |
| Insert Compatibility | LNGU15T608SRGE |
| Head Length (mm) | 44.45 |
| Head Length (Decimal Inch) | 1.7500 |
| End Mill Type | End Mill |
| Cutting Diameter (mm) | 31.75 |
| Cutting Diameter (Decimal Inch) | 1.2500 |
| Coolant Hole Diameter (mm) | 4.00 |
| Coolant Hole Diameter (Decimal Inch) | 0.1570 |
| Lead Angle | 0 |
| Weldon Flat | No |
| Toolholder Material | Steel |
| Through Coolant | Coolant Through |
| Shank Type | Modular Connection |
| Shank Length (Decimal Inch) | 0.9650 |
| Overall Length/Projection (mm) | 68.95 |
| Overall Length/Projection (Decimal Inch) | 2.7150 |
| Number of Flutes | 3 |
| Number of Cutter Inserts | 3 |
| Minimum Cutting Diameter (mm) | 31.75 |
| Minimum Cutting Diameter (Decimal Inch) | 1.2500 |
| Maximum RPM | 22100 |
| Maximum Depth of Cut (mm) | 15.50 |
| Cutting Diameter (Inch) | 1-1/4 |
| Insert Holding Method | Screw |
| Maximum Depth of Cut (Decimal Inch) | 0.6100 |
| Series | MILL 4-15 |
| Shank Length (mm) | 24.50 |
| Modular Connection Size | M16 |
