De-Sta-Co - 100mm Stroke, 0.7874" Shaft Diam, Double-Acting Cylinder, Pneumatic Slide - 339.3mm Long x 164.6mm Wide, Buna-N Seal, Linear Ball Bearing, Series DLB
Item #: 68429190
Brand: De-Sta-Co
Model #: DLB-20M-B-B-100
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Product Type | Slide |
| Overall Length (mm) | 339.30 |
| Overall Length (Decimal Inch) | 13.3583 |
| Slide Type | Base Slide |
| Series | DLB |
| Bearing Type | Linear Ball Bearing |
| Cylinder Type | Double-Acting |
| Overall Width (mm) | 164.60 |
| Overall Width (Decimal Inch) | 6.4803 |
| Mounting Orientation | Horizontal; Vertical |
| Number of Valve Positions | 2 |
| Seal Material | Buna-N |
| Minimum Operating Temperature (F) | -30 |
| Minimum Operating Temperature (C) | -35 |
| Maximum Operating Temperature (F) | 180 |
| Maximum Operating Temperature (C) | 80 |
| Minimum Operating Pressure (psi) | 40 |
| Minimum Operating Pressure (bar) | 3 |
| Maximum Operating Pressure (psi) | 100 |
| Maximum Operating Pressure (bar) | 7 |
| Stroke (mm) | 100 |
| Stroke (Decimal Inch) | 3.9370 |
| Horizontal Load Capacity (kg) | 27.20 |
| Horizontal Load Capacity (Lb.) | 60 |
| Bore Diameter (mm) | 38.10 |
| Bore Diameter (Inch) | 1-1/2 |
| Bore Diameter (Decimal Inch) | 1-1/2 |
| Special Features | Compact for Extremely Small Spaces; Repairable Cylinder |
| Shaft Diameter (mm) | 20 |
| Shaft Diameter (Decimal Inch) | 0.7874 |
