Tool-Flo - 340FLGT Grade GP50C, 4mm Cutting Width Carbide Grooving Insert - 7/16" Max Depth of Cut, Right Hand, TiN Finish
Item #: 68354489
Brand: Tool-Flo
Model #: 633240RN4C
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | FLGT |
| Insert Size | 340 |
| Material | Carbide |
| Cutting Width (mm) | 4.00 |
| Cutting Width (Decimal Inch) | 0.1575 |
| Maximum Depth of Cut (Decimal Inch) | 0.4370 |
| Manufacturer's Grade | GP50C |
| Coating | TiN |
| Cutting Direction | Right Hand |
| Insert Hand | Right Hand |
| Cutting Height (Decimal Inch) | 0.3440 |
| Multi-Use Tool | No |
| Minimum Corner Radius (Decimal Inch) | 0.0050 |
| Maximum Corner Radius (Decimal Inch) | 0.0100 |
| Coating Process | PVD |
| Series | Deep Grooving |
| ISO Number | FLGT-340R |
| Manufacturers Catalog Number | FLGT-340R |
| Insert Thickness (Decimal Inch) | 0.1950 |
