Abbott Workholding Products - Tongue & Groove Attachment, Square Soft Lathe Chuck Jaw - 3 Jaws, Steel, 3" Btw Mount Hole Ctrs, 8-1/4" Long x 3" Wide x 3" High, 7/8" & 7/8" Fastener
Item #: 59674234
Brand: Abbott Workholding Products
Model #: 21A04S
Exact Tooling IR#: 04
Features and Benefits
Pointed jaws are blanks used for smaller part diameters, allowing closer contact than square end jaws.
Product Specifications | |
---|---|
Jaw Type | Square |
Material | Steel |
Jaw Interface Type | Tongue & Groove |
Maximum Compatible Chuck Diameter (Inch) | 24 |
Maximum Compatible Chuck Diameter (Decimal Inch) | 24.0000 |
Maximum Compatible Chuck Diameter (mm) | 609.60 |
Minimum Compatible Chuck Diameter (mm) | 381.00 |
Minimum Compatible Chuck Diameter (Decimal Inch) | 15.0000 |
Minimum Compatible Chuck Diameter (Inch) | 15 |
Overall Height (mm) | 76.20 |
Overall Height (Inch) | 3 |
Distance Between Mount Hole Centers (mm) | 76.20 |
Distance Between Mount Hole Centers (Decimal Inch) | 3.0000 |
Tongue Width (Decimal Inch) | 1.2500 |
Jaw End Shape | Pointed |
Fastener Size (Inch) | 7/8 |
Fastener Size (Decimal Inch) | 0.8750 |
Number of Jaws | 3 |
Overall Width/Diameter (mm) | 76.20 |
Overall Width/Diameter (Inch) | 3 |
Overall Width/Diameter (Decimal Inch) | 3.0000 |
Overall Length (Inch) | 8-1/4 |
Overall Length (Decimal Inch) | 8.2500 |
Overall Length (mm) | 209.55 |
Tapped Hole Size | 3/8-16 |
Material Grade | 1018 |
