Schneider Electric - 16 Amp, 230 V, 1 Pole, DIN Rail Mounted Miniature Circuit Breaker - Thermal Magnetic Trip, Multiple Breaking Capacity Ratings, 78-1/2mm Deep x 91mm High x 18mm Wide
Item #: 56787617
Brand: Schneider Electric
Model #: A9F04116
Exact Tooling IR#: 04
Features and Benefits
Thermal-magnetic tripping mechanisms are designed with both a bi-metal switch and an electromagnet. They perform as a thermal breaker for low level overloads and perform as a magnetic breaker for instantaneous tripping mechanism at high levels.
| Product Specifications | |
|---|---|
| Circuit Breaker Type | Miniature Circuit Breaker |
| Amperage | 16 |
| Number of Poles | 1 |
| Breaking Capacity | 10 kA @ 220-240 V; 10 kA @ 380-415 V; 20 kA @ 100-133 V; 20 kA @ 220-240 V; 36 kA @ 12-133 V; 36 kA @ 12-60 V; 6 kA @ 440 V |
| Tripping Mechanism | Thermal-Magnetic |
| Mounting Type | DIN Rail Mounted |
| Voltage | 230 V |
| Durability | 10000 Cycles |
| Maximum Operating Temperature (F) | 158 |
| Minimum Operating Temperature (F) | -31 |
| Overall Depth (mm) | 78-1/2 |
| Overall Height (mm) | 91 |
| Overall Width (mm) | 18 |
| Standards Met | IEC Rated |
| Reset Actuator Type | Toggle Switch |
