DORMER - 1.8mm 118° High Speed Steel Jobber Drill
Item #: 80975980
Brand: DORMER
Model #: 0376867
Features and Benefits
High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Bright provides a smooth, polished finish on the tool. It increases chip flow in softer materials such as aluminum, wood and plastic.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
| Product Specifications | |
|---|---|
| Drill Bit Size (mm) | 1.80 |
| Drill Bit Size (Decimal Inch) | 0.0709 |
| Drill Point Angle | 118 |
| Drill Bit Material | High Speed Steel |
| Drill Bit Finish/Coating | Bright |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Shank Type | Straight |
| Coolant Through | No |
| Flute Length (mm) | 22.00 |
| Flute Length (Decimal Inch) | 0.8668 |
| Overall Length (mm) | 46.00 |
| Overall Length (Decimal Inch) | 1.8124 |
| Flute Length x Diameter Ratio | 4xD |
| Spiral Type | Regular Spiral |
| Specification Designation | DIN |
| Web Configuration | Tapered |
| Drill Bit Diameter Tolerance (mm) | 0.000 to -0.014 |
| Number of Flutes | 2 |
| Specification Number | DIN 338 |
| Material Grade | M2 |
| Series/List | A002 |
