Cle-Line - #35 118° High Speed Steel Jobber Drill
Item #: 57603854
Brand: Cle-Line
Model #: C19134
Features and Benefits
High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Titanium Nitride (TiN) is a multi-purpose coating which increases chip flow in softer materials. The heat and hardness resistance allows the tool to run at higher speeds than uncoated tools.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
| Product Specifications | |
|---|---|
| Drill Bit Size (Wire) | #35 |
| Drill Bit Size (Decimal Inch) | 0.1100 |
| Drill Point Angle | 118 |
| Drill Bit Material | High Speed Steel |
| Drill Bit Finish/Coating | TiN |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Shank Type | Straight |
| Coolant Through | No |
| Flute Length (Inch) | 1-1/2 |
| Flute Length (mm) | 38.10 |
| Flute Length (Decimal Inch) | 1.5000 |
| Overall Length (mm) | 66.68 |
| Overall Length (Decimal Inch) | 2.6250 |
| Overall Length (Inch) | 2-5/8 |
| Point Type | Standard |
| Shank Diameter (mm) | 2.79 |
| Shank Diameter (Decimal Inch) | 0.1100 |
| Spiral Type | Regular Spiral |
| Shank Length (mm) | 28.57 |
| Shank Length (Decimal Inch) | 1.1248 |
| Web Configuration | Tapered |
| Drill Bit Diameter Tolerance (Decimal Inch) | +0.0000 to -0.0005 |
| Web Thinning | Web-Thinned |
| Drill Bit Grade | General Purpose |
| Series/List | 1898TN |
