Tool-Flo - 4250FLG CB Grade AC3, 1/4" Cutting Width Carbide Grooving Insert - 1/4" Max Depth of Cut, Left Hand, 0.02 to 0.025" Corner Radius, AlTiN Finish
Item #: 53830089
Brand: Tool-Flo
Model #: 574050PLAC3A
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | FLG |
| Insert Size | 4250 |
| Material | Carbide |
| Cutting Width (Decimal Inch) | 0.2500 |
| Maximum Depth of Cut (Decimal Inch) | 0.2500 |
| Material Grade | C2/C3 |
| Manufacturer's Grade | AC3 |
| Coating | AlTiN |
| Cutting Direction | Left Hand |
| Insert Hand | Left Hand |
| Cutting Height (Decimal Inch) | 0.4530 |
| Lead Angle | 0 |
| Insert Seat Size | 4 |
| Chipbreaker | CB |
| Multi-Use Tool | Yes |
| Minimum Corner Radius (Decimal Inch) | 0.0200 |
| Maximum Corner Radius (Decimal Inch) | 0.0250 |
| Corner Radius (Decimal Inch) | 0.020-0.025 |
| Coating Process | PVD |
| Series | Flo-Lock |
| Rake | Neutral |
| Manufacturers Catalog Number | FLG-4250L-CB |
| Insert Thickness (Decimal Inch) | 0.2550 |
