US Motors - 1/2 hp, ODP Enclosure, No Thermal Protection, 3,450 RPM, 208-230/460 & 190/380 Volt, 60 Hz, Three Phase Standard Efficient Motor
Item #: 53653697
Brand: US Motors
Model #: EE155
Product Specifications
| Motor Type | Three Phase Standard Efficient |
| Type of Enclosure | ODP |
| Horsepower | 1/2 |
| Thermal Protection Rating | None |
| Name Plate RPMs | 3450 |
| Voltage | 208-230/460 & 190/380 |
| Frequency Hz | 60 |
| Frame Size | 56 |
| Mount Type | C-Face |
| Number of Speeds | 1 |
| Bearing Type | Ball |
| Applications | Special Application |
| Full Load Amperage | 2.1-2.2/1.1 |
| Insulation Class | B |
| Frame Material | Steel |
| Overall Length (Decimal Inch) | 11.3400 |
| Full Load Efficiency Rating | 41.6 |
| Service Factor Rating | 1.61 |
| Motor Rotation | CCW Lead End |
| PSC Code | 6105 |
