Walter - 49.85mm Body Diam, Manual Twin Cutter Boring Head - 55mm to 70mm Bore Diam - Exact Industrial Supply

Walter - 49.85mm Body Diam, Manual Twin Cutter Boring Head - 55mm to 70mm Bore Diam


Item #: 53072294
Brand: Walter
Model #: 5007820
Exact Tooling IR#: 04

Features and Benefits

Boring heads with two cutters (double edges) are used for roughing operations and can remove material twice as fast as single edge cutters .
Integral shank boring heads have the shank built into the head.
Product Specifications
Type Twin Cutter Boring Head
Actuation Type Manual
Body Diameter (mm) 49.85
Body Diameter (Decimal Inch) 1.9626
Mount Type Integral Shank
Shank Type Modular Connection
Modular Connection Size NCT50
Series Walter Boring Medium
Minimum Bore Diameter (Decimal Inch) 2.1654
Minimum Bore Diameter (mm) 55.00
Maximum Bore Diameter (mm) 70.00
Maximum Bore Diameter (Decimal Inch) 2.7559
Projection (Decimal Inch) 3.9370
$979.70

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It
