Cle-Line - #28 118° High Speed Steel Jobber Drill
Item #: 73313637
Brand: Cle-Line
Model #: C22682
Features and Benefits
High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Oxide prevents chip building, galling and welding on the workpiece. It is commonly used on low carbons, stainless steel and ferrous metals.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
| Product Specifications | |
|---|---|
| Drill Bit Size (Wire) | #28 |
| Drill Bit Size (Decimal Inch) | 0.1405 |
| Drill Point Angle | 118 |
| Drill Bit Material | High Speed Steel |
| Drill Bit Finish/Coating | Oxide |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Shank Type | Straight |
| Coolant Through | No |
| Flute Length (Inch) | 1-3/4 |
| Flute Length (mm) | 44.45 |
| Flute Length (Decimal Inch) | 1.7500 |
| Overall Length (mm) | 73.03 |
| Overall Length (Decimal Inch) | 2.8750 |
| Overall Length (Inch) | 2-7/8 |
| Point Type | Standard |
| Shank Diameter (mm) | 3.57 |
| Shank Diameter (Decimal Inch) | 0.1405 |
| Spiral Type | Regular Spiral |
| Shank Length (mm) | 28.57 |
| Shank Length (Decimal Inch) | 1.1248 |
| Web Configuration | Tapered |
| Drill Bit Diameter Tolerance (Decimal Inch) | +0.0000 to -0.0007 |
| Web Thinning | Web-Thinned |
| Drill Bit Grade | General Purpose |
| Series/List | 1899 |
