Walter-Titex - 10.5mm 140° Solid Carbide Jobber Drill
Item #: 41781790
Brand: Walter-Titex
Model #: 6901169
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Tinal TOP coatings offer high performance with low friction. It is commonly used on steel, cast iron and non-ferrous metal. Tinal TOP is a proprietary coating exclusive to Walter Titex.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
| Product Specifications | |
|---|---|
| Drill Bit Size (mm) | 10.50 |
| Drill Bit Size (Decimal Inch) | 0.4134 |
| Drill Point Angle | 140 |
| Drill Bit Material | Solid Carbide |
| Drill Bit Finish/Coating | Tinal Top Point |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Shank Type | Straight |
| Coolant Through | Coolant Through |
| Flute Length (mm) | 114.00 |
| Flute Length (Decimal Inch) | 4.4880 |
| Overall Length (mm) | 163.00 |
| Overall Length (Decimal Inch) | 6.4170 |
| Flute Length x Diameter Ratio | 5xD |
| Shank Diameter (mm) | 12.00 |
| Shank Diameter (Decimal Inch) | 0.4720 |
| Maximum Drilling Depth (Decimal Inch) | 3.7800 |
| Maximum Drilling Depth (mm) | 96.00 |
| Drill Point Length (mm) | 1.91 |
| Drill Point Length (Decimal Inch) | 0.0750 |
| Number of Flutes | 2 |
| Series/List | Xtreme INOX |
