Rocky Mountain Twist - 1/16" 135° High Speed Steel Jobber Drill
Item #: 57627457
Brand: Rocky Mountain Twist
Model #: 95003300
Features and Benefits
High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Bright provides a smooth, polished finish on the tool. It increases chip flow in softer materials such as aluminum, wood and plastic.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
| Product Specifications | |
|---|---|
| Drill Bit Size (Inch) | 1/16 |
| Drill Bit Size (Decimal Inch) | 0.0625 |
| Drill Point Angle | 135 |
| Drill Bit Material | High Speed Steel |
| Drill Bit Finish/Coating | Bright |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Shank Type | Straight |
| Coolant Through | No |
| Flute Length (Inch) | 7/8 |
| Flute Length (Decimal Inch) | 0.8750 |
| Overall Length (Decimal Inch) | 1.8750 |
| Overall Length (Inch) | 1-7/8 |
| Point Type | Standard |
| Shank Diameter (Inch) | 1/16 |
| Shank Diameter (Decimal Inch) | 0.0625 |
| Spiral Type | Regular Spiral |
| Web Configuration | Tapered |
| Drill Bit Diameter Tolerance (Decimal Inch) | +0.0000 to -0.0005 |
| Number of Flutes | 2 |
| Drill Bit Grade | Heavy Duty |
| Series/List | JH500 |
