Guhring - 0.83mm 118° High Speed Steel Jobber Drill
Item #: 71357263
Brand: Guhring
Model #: 9002050008300
Features and Benefits
High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Bright provides a smooth, polished finish on the tool. It increases chip flow in softer materials such as aluminum, wood and plastic.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
| Product Specifications | |
|---|---|
| Drill Bit Size (mm) | 0.83 |
| Drill Bit Size (Decimal Inch) | 0.0327 |
| Drill Point Angle | 118 |
| Drill Bit Material | High Speed Steel |
| Drill Bit Finish/Coating | Bright |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Shank Type | Straight |
| Coolant Through | No |
| Flute Length (mm) | 10.00 |
| Overall Length (mm) | 30.00 |
| Flute Length x Diameter Ratio | 5xD |
| Point Type | Standard |
| Shank Diameter (mm) | 0.83 |
| Shank Diameter (Decimal Inch) | 0.0327 |
| Spiral Type | Regular Spiral |
| Specification Designation | DIN |
| Web Configuration | Tapered |
| Drill Bit Diameter Tolerance (mm) | +0.000 to -0.012 |
| Specification Number | DIN 338 |
| Material Grade | M2 |
| Series/List | 205 |
