Iscar - 175GTMA Grade IC508, 1.75mm Cutting Width Carbide Grooving Insert - 2mm Max Depth of Cut, Right Hand, 0.1mm Corner Radius
Item #: 52718616
Brand: Iscar
Model #: 6402471
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | GTMA |
| Insert Size | 175 |
| Material | Carbide |
| Cutting Width (mm) | 1.75 |
| Cutting Width (Decimal Inch) | 0.0689 |
| Maximum Depth of Cut (mm) | 2.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.0787 |
| Material Grade | Submicron |
| Manufacturer's Grade | IC508 |
| Cutting Direction | Right Hand |
| Insert Hand | Right Hand |
| Multi-Use Tool | No |
| Corner Radius (mm) | 0.10 |
| Corner Radius (Decimal Inch) | 0.0039 |
| Coating Process | PVD |
| Series | Cut Grip |
| ISO Number | GTMA 16ER/IL 175 |
| Manufacturers Catalog Number | GTMA 16ER/IL 175 |
