Sandvik Coromant - 327 GMM Grade 1025 Carbide Groove Milling Tip Insert - TiCN/TiN Finish, 6 Flutes, 34.7mm Cutting Diam, 10mm Depth of Cut, 6.25mm Extension, 0.008" Cnr Rad, 0° Helix
Item #: 52070661
Brand: Sandvik Coromant
Model #: 6010123
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
TiCN/TiN is a multi-layered coating designed to increase tool life. It is commonly used at high cutting speeds for smoothing and finishing of the workpiece.
| Product Specifications | |
|---|---|
| Series | CoroMill 327 |
| Milling Tip Style | 327 |
| Milling Tip Type | Groove Milling |
| Material | Carbide |
| Cutting Diameter (mm) | 34.70 |
| Cutting Diameter (Decimal Inch) | 1.3661 |
| Manufacturer's Grade | 1025 |
| Depth of Cut (mm) | 10.00 |
| Number of Flutes | 6 |
| Coating | TiCN/TiN |
| Corner Radius (Decimal Inch) | 0.008 |
| Coating Process | PVD |
| Chipbreaker | GMM |
| Cutting Width (Decimal Inch) | 0.0984 |
| Extension From Holder (mm) | 6.25 |
| Extension From Holder (Decimal Inch) | 0.2461 |
| Helix Angle | 0 |
| Style | 327-GM |
| Manufacturers Catalog Number | 327R14-35 25002-GMM 1025 |
