Rocky Mountain Twist - 27/64" 135° High Speed Steel Jobber Drill
Item #: 57628513
Brand: Rocky Mountain Twist
Model #: 95004823
Features and Benefits
High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Oxide/gold finish provides a polished finish and prevents chip building, galling and welding on a workpiece. It is commonly used on low carbon, stainless steel and ferrous metals.
Parabolic flutes are constructed with a wider flute shape for increased chip flow.
| Product Specifications | |
|---|---|
| Drill Bit Size (Inch) | 27/64 |
| Drill Bit Size (Decimal Inch) | 0.4219 |
| Drill Point Angle | 135 |
| Drill Bit Material | High Speed Steel |
| Drill Bit Finish/Coating | Oxide/Gold |
| Flute Type | Parabolic |
| Cutting Direction | Right Hand |
| Shank Type | Straight |
| Coolant Through | No |
| Flute Length (Inch) | 3-15/16 |
| Flute Length (Decimal Inch) | 3.9375 |
| Overall Length (Decimal Inch) | 5.3750 |
| Overall Length (Inch) | 5-3/8 |
| Point Type | Split Point |
| Shank Diameter (Decimal Inch) | 0.4219 |
| Number of Flats | 3 |
| Web Configuration | Tapered |
| Drill Bit Diameter Tolerance (Decimal Inch) | +0.0000 to -0.0010 |
| Number of Flutes | 2 |
| Web Thinning | Web-Thinned |
| Drill Bit Grade | Heavy Duty |
| Series/List | JH522P |
