Manual Surface Grinder: 60″ Table Length, 24″ Table Width, 3 Phase, 1,750 RPM, 230 & 460V 10 hp, 5″ Arbor Hole Dia, 16″ Wheel Dia, 16″ Wheel Width
Item #: 50705730
Brand: Clausing
Model #: CSG2460ASDIII
Product Specifications
| Arbor Hole Diameter (Decimal Inch) | 5.0000 |
| Arbor Hole Diameter | 5.0 in; 127.0 mm; 5 in |
| Arbor Hole Diameter (Inch) | 5 |
| Arbor Hole Diameter (mm) | 127.00 |
| Operation Type | Automatic |
| Machine Type | Grinder |
| Spindle Speed | 1750.0 RPM |
| Spindle Speed (RPM) | 1750.00 |
| Table Length (Inch) | 60 |
| Table Length | 60 in |
| Table Width (Inch) | 24 |
| Wheel Diameter (Inch) | 16 |
| Table Width | 24 in |
| Wheel Diameter | 16 in |
| Wheel Width (Decimal Inch) | 16.0000 |
| Wheel Width (Inch) | 16 |
| Wheel Width | 16.0 in |
| Horsepower | 10.00 |
| Phase | 3 |
| Maximum Cross Grinding Width (Decimal Inch) | 24.0000 |
| Maximum Cross Grinding Width (Inch) | 24 |
| Maximum Longitudinal Grinding Length (Inch) | 68 |
| Hydraulic Motor Horsepower (HP) | 5.00 |
| Maximum Manual Crossfeed Transverse Travel (Inch) | 27 in |
| Maximum Cross Grinding Width | 24.0 in |
| Maximum Spindle Centerline To Table Distance | 28.3 in |
| Maximum Spindle Centerline to Table Distance (mm) | 28.30 |
| Maximum Longitudinal Table Travel | 63.0 in |
| Maximum Longitudinal Grinding Length | 68.0 in |
| Feed Per Graduation Of Handwheel | 0.0 in |
| Maximum Manual Crossfeed Transverse Travel | 27 in; 27.0 in |
| Feed Per Revolution Of Handwheel | 0.004 in |
| Feed Rate Per Graduation Of Handwheel | 0.0 mm |
| Feed Rate Per Revolution Of Handwheel | 0.1 mm |
| Overall Length (Inch) | 177 |
| Overall Length (Decimal Inch) | 177.0000 |
| Voltage | 460; 230 |
| Voltage | 230/460V (Optional 208V) V |
| Overall Length | 177.0 in |
| Vertical Downfeed Handwheel Per Graduation | 0.0 in; 0.001 mm |
| Vertical Downfeed Handwheel Per Revolution | 0.004 in; 0.1 mm |
| Vertical Downfeed Step Feed (mm) | 1.0000 |
| Vertical Downfeed Step Feed (Decimal Inch) | 1.002500 |
| Max. Longitudinal Grinding Length (Decimal Inch) | 68.0000 |
| Vertical Downfeed Step Feed | 1.0 mm; 1.0025 in |
| Max. Spindle Center to Table Dist. (Decimal Inch) | 28.3000 |
| Max. Hydraulic Long. Table Travel (Decimal Inch) | 63.0000 |
| Max. Manual Cross Transverse Travel (Decimal Inch) | 27.000000 in |
| Feed Per Revolution of Handwheel (Decimal Inch) | 0.0040 |
| Feed Rate Per Revolution of Handwheel (mm) | 0.10 |
| Vertical Down Handwheel Per Rev. (Decimal Inch) | 0.0040 |
| Vertical Downfeed Handwheel Per Revolution (mm) | 0.10 |
 | |
| MSC Part # | 50705730 |
| Mfr Part # | CSG2460ASDIII |
