Kyocera - 0.413" Min Bore Diam, 5" OAL, 0.312" Shank Diam, S-SCLP-A Indexable Boring Bar - 0.63" Max Bore Depth, CPGT 215 Insert, Screw Holding Method
Item #: 50415132
Brand: Kyocera
Model #: 8826485
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Toolholder Style | S-SCLP-A |
| Series | Dynamic Bars |
| Minimum Bore Diameter (Decimal Inch) | 0.4130 |
| Hand of Holder | Right Hand |
| Maximum Bore Depth (Decimal Inch) | 0.6300 |
| Overall Length (Inch) | 5 |
| Overall Length (Decimal Inch) | 5.0000 |
| Shank Diameter (Decimal Inch) | 0.3120 |
| Insert Compatibility | CPGT 215 |
| Through Coolant | Yes |
| Multi-Use Tool | Yes |
| Multi-Use Application | Internal Facing |
| Number of Inserts Used on Toolholder | 1 |
| Insert Holding Method | Screw |
| Rake | Negative |
| Lead Angle | 5 |
| Center to Cutting Edge (Decimal Inch) | 0.1970 |
| Rake Angle | -10 |
| Coolant Hole Diameter (mm) | 2.50 |
| Coolant Hole Diameter (Decimal Inch) | 0.0984 |
| Complete Insert Compatibility | CPGT 215 |
| Toolholder Material | Steel |
