Dorian Tool - TPG221 UEN Grade DNP25GT Carbide Turning Insert - TiN Finish, 60° Triangle, 1/4" Inscr Circle, 1/8" Thick, 1/64" Corner Radius
Item #: 47153309
Brand: Dorian Tool
Model #: 73310171607
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | TPG |
| Insert Size | 221 |
| Material | Carbide |
| Inscribed Circle (Decimal Inch) | 0.2500 |
| Inscribed Circle (Inch) | 1/4 |
| Thickness (Inch) | 1/8 |
| Thickness (Decimal Inch) | 0.1250 |
| Corner Radius (Inch) | 1/64 |
| Corner Radius (Decimal Inch) | 0.0156 |
| Manufacturer's Grade | DNP25GT |
| Coating | TiN |
| Material Grade | C1/C2 |
| Chip Breaker | UEN |
| Insert Length (Decimal Inch) | 0.4331 |
| Hole Diameter (mm) | 2.72 |
| Hole Diameter (Decimal Inch) | 0.1070 |
| ISO Number | TPG-110304-UEN-DNP25GT |
| Rake | Positive |
| Rake Angle | 7 |
| Relief Angle | 11 |
| Coating Process | PVD |
| Manufacturers Catalog Number | TPG-221-UEN-DNP25GT |
| Included Angle | 60 |
| Cutting Direction | Neutral |
| Maximum Depth of Cut (mm) | 6.10 |
| Maximum Depth of Cut (Decimal Inch) | 0.2400 |
| Insert Holding Method | Clamp |
| Cutting Edge Style | Honed |
| MultiUseTool | No |
| Shape | Triangle |
