Walter - MPMT1204 F57 Grade WKP35G Carbide Milling Insert - TiAlN/TiN Finish, 4.76mm Thick, 12mm Inscribed Circle, 0.8mm Corner Radius
Item #: 46627147
Brand: Walter
Model #: 7347275
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | MPMT |
| Insert Size | 1204 |
| Material | Carbide |
| Material Grade | K35/P35/K35 |
| Manufacturer's Grade | WKP35G |
| Coating | TiAlN/TiN |
| Length (Inch) | 1/2 |
| Inscribed Circle (mm) | 12.00 |
| Thickness (mm) | 4.76 |
| Corner Radius (mm) | 0.80 |
| Hole Diameter (mm) | 5.50 |
| Relief Angle | 11.000 |
| Rake | Positive |
| Coating Process | CVD |
| Shape | Diamond |
| Insert Hand | Neutral |
| Chipbreaker | F57 |
| Maximum Depth of Cut (Decimal Inch) | 0.5000 |
| Manufacturers Catalog Number | MPMT120408-F57 WKP35G |
