Manifolds; Inlet Size: 1/4 NPT; Outlet Size: 0.438; Number of Inlet Ports: 1; Number Of Outlet Ports: 3; Outlet Center to Center Distance: 1.50; Overall Length (Decimal Inch): 3.1300
Item #: 70039029
Brand: Raptor Workholding
Model #: RWP-AIR-501
Product Specifications
| Inlet Size | 1/4 NPT |
| Outlet Size | 0.438 |
| Number of Inlet Ports | 1 |
| Number Of Outlet Ports | 3 |
| Outlet Center to Center Distance | 1.50 |
| Overall Length (Decimal Inch) | 3.1300 |
| Height (Inch) | 1-1/2 |
| Body Material | Aluminum |
| Color | Black |
| Finish | Anodized |
| Outlet Location | Three Sides |
| Maximum Working Pressure (Psi - 3 Decimals) | 125.000 |
| Standards | None |
| Minimum Working Pressure (psi) | 25.0 |
| Seal Material | None |
| Minimum Temperature (Deg F - 3 Decimals) | 0.000 |
| Maximum Pressure (Psi - 2 Decimals) | 125.00 |
| Mounting Hole Size Diameter (Decimal Inch) | 0.2650 |
| Height (Decimal Inch) | 1.500000 |
| UNSPSC Code | 40141734 |
| Inlet Size | 1/4 NPT |
| Outlet Size | 0.438 |
| Number of Inlet Ports | 1 |
| Number Of Outlet Ports | 3 |
| Outlet Center to Center Distance | 1.50 |
| Overall Length (Decimal Inch) | 3.1300 |
| Height (Inch) | 1-1/2 |
| Body Material | Aluminum |
| Color | Black |
| Finish | Anodized |
| Outlet Location | Three Sides |
| Maximum Working Pressure (Psi - 3 Decimals) | 125.000 |
| Standards | None |
| Minimum Working Pressure (psi) | 25.0 |
| Seal Material | None |
| Minimum Temperature (Deg F - 3 Decimals) | 0.000 |
| Maximum Pressure (Psi - 2 Decimals) | 125.00 |
| Mounting Hole Size Diameter (Decimal Inch) | 0.2650 |
| Height (Decimal Inch) | 1.500000 |
| UNSPSC Code | 40141734 |
| MSC Part # | 70039029 |
| Mfr Part # | RWP-AIR-501 |
| Country of Origin Country of Origin is subject to change | UNITED STATES |
