USDI - 1 Row, 1-3/8" OD, 3/4" Bore Diam, Round Double Seal Conveyor Roller Bearing - 180 Lb Capacity, 550 Max RPM, with Flange, Steel with Zinc Housing
Item #: 36560076
Brand: USDI
Model #: ASF-107-6
Exact Tooling IR#: 04
Features and Benefits
Conveyor roller bearings are designed to accommodate loads where high levels of exposure to contamination are present. They are economical and are used in conveyor systems.
Double seal bearings are factory lubricated with oil or grease and designed to retain lubricants while keeping contaminates out. The seal is on each side of the bearing and is located on the outer race making some contact with the inner race.
Radial ball bearings with a flange axially locates the bearing in the housing and eliminates the need for housing shoulders or snap ring.
Round bore bearings are designed for mounting on round shafts.
| Product Specifications | |
|---|---|
| Type | Conveyor Roller Bearing |
| Style | Double Seal |
| Bore Diameter (Inch) | 3/4 |
| Outside Diameter (Decimal Inch) | 1.3750 |
| Flange Type | With Flange |
| Number of Rows | 1 |
| Bore Type | Round |
| Housing Material | Zinc |
| Snap Ring Included | Without Snap Ring |
| Static Load Capacity (Lb.) | 180 |
| Dynamic Load Capacity (Lb.) | 180 |
| Ball Material | Steel |
| Maximum RPM | 550 |
