Walter-Titex - JPDJ, Left Hand Cut, 93° Lead Angle, 1/2" Shank Height x 1/2" Shank Width, Indexable Turning Toolholder - 4-3/4" OAL, DXGU-.. Insert Compatibility, Series Miniforceturn
Item #: 36527117
Brand: Walter-Titex
Model #: 6712889
Exact Tooling IR#: 04
Features and Benefits
Aluminum chromium nitride (AlCrN) has higher-heat resistance than AlTiN. It is commonly used for machining aircraft and aerospace material, nickel alloys, stainless steel, titanium, cast iron and carbon steel.
| Product Specifications | |
|---|---|
| Hand of Holder | Left Hand |
| Toolholder Style | JPDJ |
| Series | Miniforceturn |
| Lead Angle | 93 |
| Shank Width (Decimal Inch) | 0.5000 |
| Shank Height (Decimal Inch) | 0.5000 |
| Overall Length (Decimal Inch) | 4.7500 |
| Insert Compatibility | DXGU-.. |
| Multi-Use Application | Profiling; Turning |
| Insert Holding Method | Screw |
| Head Length (Decimal Inch) | 0.6250 |
| Drill Bit Material | Carbide |
| Series/List | DB133-05-A0 |
| Drill Bit Finish/Coating | AlCrN |
| Cutting Direction | Right Hand |
| Maximum Drilling Depth (mm) | 18.00 |
| Material Grade | Carbide |
| Flute Length (mm) | 22.00 |
| Flute Length (Decimal Inch) | 0.866 |
| Drill Point Angle | 140 |
| Drill Bit Size (Decimal Inch) | 0.1004 |
| Drill Bit Size (mm) | 2.55 |
| Through Coolant | No |
| Shank Diameter (mm) | 3 |
| Shank Diameter (Inch) | 0.118 |
| Overall Length (mm) | 62 |
| Overall Length (Decimal Inch) | 2.441 |
