Tritan - 5/8" Bore Diam, 1-3/8" OD, Double Seal Deep Groove Radial Ball Bearing - 11/32" Wide, 1 Row, Round Bore, 734 Lb Static Capacity, 1,347 Lb Dynamic Capacity
Item #: 35433408
Brand: Tritan
Model #: R10 2RS PRX
Exact Tooling IR#: 04
Features and Benefits
Deep groove ball bearings are used for high and very high speeds in operations, requiring little maintenance. They are designed with balls rolling between an inner and outer raceway. They are commonly used in pumps, gear motors and electric motors.
Double Seal Bearings are factory lubricated with oil or grease and designed to retain lubricants while keeping contaminates out. The seal is on each side of the bearing and is located on the outer race making some contact with the inner race.
Round bore bearings are designed for mounting on round shafts.
| Product Specifications | |
|---|---|
| Type | Deep Groove |
| Style | Double Seal |
| Bore Diameter (Inch) | 5/8 |
| Outside Diameter (Inch) | 1-3/8 |
| Width (Inch) | 11/32 |
| Flange Type | Without Flange |
| Number of Rows | 1 |
| Bore Type | Round |
| Snap Ring Included | Without Snap Ring |
| Static Load Capacity (Lb.) | 734 |
| Static Load Capacity (Nm) | 3265 |
| Dynamic Load Capacity (Lb.) | 1347 |
| Dynamic Load Capacity (Nm) | 5992 |
| Bearing Number | R10 |
